punkt nr.: DS-6Q
Model: DS-6Q
8Ω Stereo Power (RMS): 625W X 4CH
4Ω Stereo Power (RMS): 1,250W X 4CH
Certification: CE, ROHS
Warranty: 3 Years
Special service: OEM service offered
beschreibung
Sinbosen Audio DS Series Amplifier
  DS-6Q DS-9K DS-14K DS-7K DS-10Q DS-20Q DS-22Q
8 ohm Stereo Power  (RMS) 625WX4 1800WX2 2400WX2 1500WX2 1350WX4 2200WX4 2500WX4
4 ohm Stereo Power  (RMS) 1250WX4 3000WX2 4400WX2 2800WX2 2100WX4 4000WX4 4650WX4
8 ohm Bridged Power (RMS) 2500WX2 6000W 8800W 5600W 4200WX2 8000WX2 9300WX2
4 ohm Bridged Power (RMS) 3000WX2 9000W 14000W 7000W 5000WX2 9000WX2 15000WX2
Frequency Response(+o/-0.3dB,1W/8Ω): 20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1W: <0.1%
Signal-to-Noise Ratio: >112 dBA
Channel separation (Crosstalk) at 1 kHz : >70 dB
Input Connectors (per channel): 3 pin XLR, electronically balanced
Output Connectors (per channel): Binding Posts 2-pole
Class: TD
TourClass Protection: ACL, IGM, AutoRamp, short circuit, DC voltage, turn on/off transient, current inrush, sub/ultrasonic input
Operating voltage, 220V / 110V nominal: 180-240 V / 90-130 V selectable
Voltage Gain(dB): 23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance: 20 kOhm
Level adjustment (per ch.): Front panel potentiometer, 31 positions detented from -inf to 0 dB


DS-6Q Feature:
· 4 Channel
Class TD Switching power amplifier, compact structure, reasonable.
· 4 x 625 Watts into 4 Ohms,4 x 1,300 Watts into 8 Ohms
· Neutrik XLR*/speakon connectors.
· Use Original Siemens high-quality capacitor 3300uf 200V.
· Use Original ONSEMI type PNP power output transistor.
· High-quality fans from TaiWan.
· Separately controllable on Gain.
· Scalable Voltage Peak Limiter (VPL).
· Bridge-mode operation for Touring Applications.
· Comprehensive protection scheme.
· Each channel with independent adjustable peak output voltage, the amplifier can be very easy to drive different power sizes speakers .
· Intelligent protection circuit provides advanced technology to protect the internal circuits and connected loads, can in extreme conditions to protect the amplifier and speakers.
